Associate professor Kazuhiro Takahashi and Tomoya Maeda (a second-year master’s student) and other members of the Department of Electrical and Electronic Information Engineering at Toyohashi University of Technology have developed a semiconductor sensor capable of detecting ultra-low concentrations of tumor markers, on chips made using semiconductor micromachine technology. The research team succeeded in detecting only prostate cancer antigens by adsorbing disease-derived marker molecules contained in blood and other bodily fluids into the surface of a flexibly deforming nanosheet, using the principle of converting the force caused by the interaction between the adsorbed molecules into the amount of deformation of the nanosheet. Testing chips, formed in sizes of several millimeters across using semiconductor technologies, are expected to be used as Internet of Things (IoT) biosensors for home-based testing.
Current Testing Options
Measuring devices that perform disease tests simply and quickly from small amounts of blood, urine, saliva, and other bodily fluids are extremely important for accurate diagnosis and verifying the effectiveness of therapeutic treatments. Substances that change in concentration according to specific diseases contained in such bodily fluids are called biomarkers. As one example, it has been reported that patients with severe cases of COVID-19 have different concentrations of multiple biomarkers in their blood than those with mild cases of the disease, and it is expected that this can be used to predict severity by examining those markers. One of the most widely used marker tests is the PSA test. PSA is a marker that increases in the blood as a result of prostate cancer. Marker screening of saliva is also carried out as a less invasive form of cancer risk testing. The marker testing equipment that has been put to practical use so far is a detection method that reads color changes using a labeling agent. Because it takes time and effort to perform labeling, many of the devices used are relatively large, and the use of this method was limited to testing at large hospitals. Accordingly, if portable IoT biosensors are actualized, it is expected to expand testing opportunities and contribute to the advancement of telemedicine.
The research team is researching a micro-scale testing chip that uses flexibly deforming nanosheets formed using semiconductor micromachine technology to determine the presence or absence of disease. The principle of the method is that antibodies which catch the marker (antigen) molecules to be detected are fixed onto the nanosheet in advance, and the deformation of the thin film—caused by the force of the adsorbed antigens electrically repelling each other—is read. In this sensor—which was designed to deform sensitively in response to the adsorption of biomolecules—however, there was a problem in that the film deteriorated as a result of fixing antibodies to it. In the past, the biological functional layer on the surface was produced by spin coating and ultraviolet irradiation, but ultraviolet irradiation was considered to be one of the factors that degraded nanosheet films. The research team changed the materials used from the conventional method, and instead adopted a method of depositing the functional layer by chemical vapor deposition. As a result, they created a thinner, more uniform, and less degraded sensor chip.
Using the biosensors developed on this occasion, the team conducted an experiment detecting prostate cancer biomarkers, and succeeded in detecting 100 attograms (equivalent to three attomolars in terms of molar concentration) contained in one milliliter of fluid. This lower limit detection concentration is comparable to that of large testing devices using labeling agents, and could be applied in ultra-sensitive testing with portable-scale testing devices. Furthermore, since it is possible to detect how nanosheets deform by adsorption of molecules in real time, it is possible to detect disease-derived molecules faster than in comparison with testing equipment using labeling agents.
Future Outlook
The research team now plans to demonstrate that biomarkers can be detected on semiconductor sensors that integrate analytical integrated circuitry, with a view to practical applications in portable testing equipment. In addition, replacing probe molecules applied to the surface of nanosheets will enable the creation of numerous types of comprehensive disease diagnosis tests, which are expected to lead to the early-stage detection of more diseases in the future. By implementing IoT biosensors in society, the team aims to help create a society where everyone will be able to take tests easily, and undergo medical examinations by physicians remotely.
– This press release was provided by Toyohashi University of Technology
